Features of CNC Foam Cutting Machine
Application of CNC Foam Rubber Board Cutting Machine
CNC Foam Rubber Board Cutting Machine can cut foam boards and rubber pads with different thicknesses between 1-10 cm. It can also cut materials of different shapes and patterns quickly. There is no burr on the edge of the cut finished product. The production speed of non-standardized products is accelerated and the precision is higher.
Multi-purpose board cutting machine can also cut other materials : fabric, leather, cardboard, plastic, paper, rubber, EVA foam, and it can cut many types of foam, such as closed cell foam, rubber foam, foamex, foam core, KT board, EPE foam, polyethylene foam, PE foam, PVC foam, etc. It’s widely used for packaging protection, advertising display, termal insulation, model & mock up making, puzzle and pattern cutting, etc.
Other material–welcome send the sample to test with our machine.
Advantage of CNC Foam Rubber Board Cutting Machine
1）Swiss imported Oscillating Knife can process the soft material, like carton, rubber, sponge, etc.
2) Carousel tool changer with tool storage, quick change tool
3) High configuration or components of this type of router, can be able to promise router smooth and stable running.
4) Multi-purpose. In addition to the cutting function, this Rubber Board Cutting Machine can also achieve indentation, punching, scribing and other functions
Specifications of CNC Foam Rubber Board Cutting Machine
| Technical parameters | AOL-FH1625-PS, AOL-FH1825-PS, |
|---|---|
| Effective working area | 1600*2500MM, 1800*2500MM |
| Multi-function cutting head | The combination of Multi-function cutting head and holders, be with full cut, kisscut, creasing wheel,v-cut and laser red light positioning functions, CCD positioning, Camera extract large contour to cut |
| Tools | Universal Drawing Tool, Creasing Wheel Tool |
| Moving speed | 800-1500mm/s |
| Repeat precIsion | ±0.05mm |
| Interface | Enternet port |
| Control panel | LCD touch screen |
| Drive system | Imported servo motor, linear guid, synchronous belt, screw |
| Cutting material | Foam, Rubber, Papper, PET, Acoustic Board Panels, Glass fiber, glass fiber cotton, prepreg, carbon fiber, carbon fiber felt, boron fiber, aramid fiber, ceramic fiber, soft glass, PVC, leather, sponge composite skin, XPE material, wire ring, leather, soft glass , silicone, rubber material etc composite soft material, etc. |
| Instruction system | HP- GL Compatible format |
| Rated power | 2. 2KW |
| Rated voltage | 220V |
| Cutting thickness | ≤50mm(According to different material) |
| Material fixed way | Vacuum adsorption |
| Auto feeding system | Acuum sucker adsorpting sheet |
Why Choose CNC Foam Rubber Board Cutting Machine
Customer pain points in CNC Foam & Rubber Industry
1. The utilization rate of manual discharge is too low, which increases the cost of the enterprise
2. High-end products have high technical requirements, which cannot be achieved by traditional craftsmanship
3. Special materials have occupational hazards to the human body
4. The hardness of special materials is extremely high, which cannot be achieved by traditional cutting.
CNC Foam Rubber Board Cutting Machine can solve the above difficulties
1. Super nesting software, material utilization rate increased by more than 10%
2. Select Japanese Panasonic servo system to increase production efficiency by more than five times
3. Automatic pulling and unloading, saving time, effort and more environmental protection
4. The anti-static system of the whole machine to maximize the protection of personnel safety
5. Professional R&D team can provide assembly line supporting plan
Service OF AOL
1.Three years warranty,main parts are free of charge when problems happened during the guarantee period.
2.We provide the consumable parts at agent price when you need replacement.
3.24 hours online service each day,free technical support with different languages.
4.We provide door to door technical support ,if necessary.
FAQ Of Digital Cutting Machine for PET Acoustic Board Panels
AOL is one of the famous professional CNC Cutting Machine manufacturers and suppliers in China. Choose CNC Foam Rubber Board Cutting Machine is right. If you need it, please contact us.
Question 1: I want to buy this machine,what suggestion can you give?
Answer: Please tell me:what material do you process? What’s the size of your material?
Question 2: What’s the delivery cost & time?
Answer: Please tell me your sea port name,i check shipping cost. After production,we’ll deliver ASAP.
Question 3: Have you exported to our country?
Answer: We have been in this field for 10 years,we have CE,ISO,FDA certificates,have exported to Europe,South America,Arab,Asia,Russia,Spain,Australia and many more countries.
Question 4: This is the first time I use this kind of machine, is it easy to operate?
Answer:There are english manual or guide video that show how to use machine.
If there is still have any question, please contact us by e-mail / skype/ phone /trademanager online service at any time.
Question 5: If machine have any problem after I receive it, how can I do ?
Answer:Free parts send to you in machine warranty period if machine have any problem. If the parts less than 0.5KG, we pay the postage.
About AOL
AOL CNC Equipment Co., Ltd. is a high-tech enterprise specializing in the development, manufacturing, sales and after-sales service of flexible material cutting and laser cutting machines, mainly including CNC intelligent blade cutting machines. Various types of cutting machines such as labeling machines can meet the cutting different materials, and are widely used in advertising packaging, composite materials, carpet industries, clothing textiles, automotive interiors, and leather industries.
In addition, AOL also has an independent CNC cutting machine brand AOYOO.
The company is strong. AOL CNC Equipment Co., Ltd. is a high-tech industry in China and an AAA-level credit enterprise. The product quality has undergone multiple tests and the after-sales system is complete.
It has provided reliable CNC cutting machines for more than 25000 users worldwide. Provide professional industry cutting assembly line solutions for many users,
AOL is committed to multi-industry flexible material cutting solutions for global users. The annual output of high-quality CNC cutting machines in the AOL factory can reach 2000 units, and each machine is provided with a three-year warranty service.
There are many machine models produced by AOL, such as carton cutting machine, fabric cutting machine, gasket cutting machine and so on. Welcome to learn more.
Please leave your contact information, and briefly describe the thickness and size of your cutting material, we will recommend a suitable model for you.
