Over time, we have seen print and cut service providers play a unique and critical role in the modern business environment, providing high-quality print and cut services to meet needs ranging from packaging solutions to legal documents. In recent years, the integration of artificial intelligence (AI) technology has brought revolutionary changes to various industries, and the printing industry is no exception. By utilizing the power of artificial intelligence, it can bring convenience to more manufacturers in the advertising packaging industry and save unnecessary expenses, so how can printing and cutting service providers use artificial intelligence to create more profits?
The staff prints the required materials through professional printing equipment. If the efficiency can be improved in the subsequent cutting process, can multiple small batch production be added, thereby saving labor costs and time expenses. Here we recommend you to use AOL printing material cutting equipment!
With the unique automatic tool setting system and high-definition camera positioning, precise cutting can be achieved. The motor used in this device is a Japanese Panasonic servo motor. It cuts faster and more stably. AOL printing material cutting equipment is also equipped with a height sensor, which can detect the plane of the table, and flexibly change the cutting depth according to the detection data, so as to achieve perfect cutting without damaging the felt.
Advantages of AOL advertising packaging industry cutting machine
1. High frequency electric oscillating/vibration knife: There would be much more cutting material and cutting thickness to meet different demands of customers.
2. Integration of intelligent cutting/ indentation/drawing –meet your whole trip of creative processing: cutting labels at all shapes, cutting and indentation of carton in all shapes.
3. Precise auto-positioning system: Equipped with HD CCD camera, it could achieve the precise auto-positioning of all materials and the automatic registering, which solves the imprecise manual positioning and the deforming printing, so as to reach the simple and precise cutting.
4. Barcode management system: Scan the barcode to read the cutting task rapidly.
5. Automatic feeding system: Automatic feeding system to make the cutting more efficient.
Various parameters of the cutting machine
| Technical parameters | 1070 |
|---|---|
| Effective working area10 | 1000*700mm |
| Multi-function cutting head | The combination of Multi-function cutting head and holders, be with full cut, kisscut, creasing wheel,v-cut and laser red light positioning functions, CCD positioning, Camera extract large contour to cut |
| Tools | Oscillating knife, Milling tool, pneumatic knife, V-cut, crease wheel, kiss cut, drag knife |
| Overall size | 2520*1080*1280mm L’W’H |
| Moving speed | 800-1500mm/s |
| Repeat precIsion | ±0.05mm |
| Interface | Enternet port |
| Control panel | LCD touch screen |
| Drive system | Imported servo motor, linear guid, synchronous belt, screw |
| Cutting material | Paperboard, grey board, KT board, pvc foam board, honeycomb board, car sticker, lamp piece, PP Adhesive material, printing cloth, banner cloth, all kinds of corrugated board, EPE foam, EVA, PVC board, acrylic board, thick foam and so on |
| Instruction system | HP- GL Compatible format |
| Rated power | 2. 2KW |
| Rated voltage | 220V |
| Cutting thickness | (According to different material) |
| Material fixed way | Vacuum adsorption |
| Auto feeding system | Acuum sucker adsorpting sheet |
About AOL
After sale service
1).Three years free warranty(except consumable parts), main parts are free of charge.when problems happened because of quality problem during this period.
2).Life time free maintenance service.
3).Consumable parts(like blade, table cover) alway supply at cost price when needed.
4).A free operation training in our factory, and if don’t have enough time, we will send a detailed training video.
5).24 hours online service, free technical support with different languages.
6).Door to door technical support when needed.
If you could kindly provide us a few information, that would be very helpful for us.
Eight reasons to AOL CNC cutting machine
1. Advanced brand: ten years of professional CNC blades
2. R & D advantages: a number of patented technologies, so that the company has a deep deposit
3. Quality assurance: all products have passed European CE certification. US FDA certification
4. High-quality materials: All CNC cutting machine accessories are selected from industry-leading brands.
5. Advanced technology: starting from Germany, foreign advanced technology, technical support
6. High efficiency: implement one-to-one service to improve the efficiency of corporate feedback
7. Personalized customization: With the development and design functions, customers can do whatever they want
8. After-sales service: provide three-year warranty service and 24-hour online solutions.
About AOL
AOL CNC Equipment Co., Ltd. is a high-tech enterprise specializing in the development, manufacturing, sales and after-sales service of flexible material cutting. Various types of cutting machines such as labeling machines can meet the cutting processing of metal materials and flexible materials of different materials, and are widely used in advertising packaging, composite materials, carpet industries, clothing textiles, automotive interiors, and leather industries.
The company is strong. AOL CNC Equipment Co., Ltd. is a high-tech industry in China and an AAA-level credit enterprise. The product quality has undergone multiple tests and the after-sales system is complete. It has provided reliable CNC cutting machines to more than 8,000 users worldwide. Provide professional industry cutting assembly line solutions for many users.
AOL CNC cutting machine is suitable for product customization or sample cutting. It can automatically and accurately perform cutting and other processing. CNC cutting machine supports different types of cutting, (such as through cutting, kiss cutting. V-groove, compliance, milling, etc.
Want to know more machine performance and other information, please leave a message for professional reply.
AOL intelligent blade cutting machine has high precision and high efficiency. Our professional after-sales service can provide automatic cutting solutions for various industries.
