Hardware feature of Digital Corrugated Cutting Machine
1. Integrated feeding body:
Digital corrugated cutting machine Ingeniously feeding and cutting integrated body, single feeding up to 1800mm and cutting size synchronization, reducing the efficiency loss of frequent feeding, so that the production capacity is greater.
2. Twill rack:
In order to make the transmission more efficient and smoother, Corrugated box machine use a twill gear rack with a higher degree of coincidence, the gear rack is Sweden Linden.
3. Thick steel bed:
The thickness of digital corrugated cutting machine some steel plate parts is 12-20mm. It ensures the corrugated box machine will be non-deformation permanently.
4. safety Device：
Equipped with an infrared automatic sensor device, the Safety Device provides a safe working environment.
Software advantage of Digital Corrugated Cutting Machine
1 .Convenient operation: The AOL software system is powerful and easy to operate, which is one of the important features of all. The software updated, easier operation, optimized, and upgraded the graphics editor. Just have a video tutorial or manual you can quickly master the operation of AOL.
2. Smooth Line： The system simplifies the process of cut line creation, select the image file format that needs to be edited, the system then automatically create cut files.
3.Intelligent Material Library： The system contains the processing ways for hundreds of materials from more than ten industries. The system can choose the best cutting tool and blade according to the selected material.
4.Tabletop height compensation function: The flatness of the tabletop is detected by a high-precision distance detector, and the tabletop is corrected in real-time by software to avoid the inconsistent cutting depth caused by the inconsistency between the tabletop and the tool drop, ensuring the perfect cutting result
Application material of Digital Corrugated Cutting Machine
AOL CNC corrugated cardboard cutting machine is widely used in packaging and signs, including, paper, board, sticker, vinyl and so on. It is the key equipment for small volume production and sample making. This commercial digital cutting machine provides perfect solutions for printing.
Cutting display of Digital Corrugated Cutting Machine
Parameter of Digital Corrugated Cutting Machine
| Technical parameters / model | AOL-1625 | AOL-1825 | AOL-2125 | Accept special model customization | ||
|---|---|---|---|---|---|---|
| Effective working area | 1600x2500mm | 1800x2500mm | 2100X2500 | |||
| Multi-head optional | Double head optional efficiency doubled, double gantry optional, double head mutual shift optional, length can be customized | |||||
| Multi-function tool | Vibrating knife full cutting, high power active round knife, punching tool, pneumatic knife, multi-layer knife | |||||
| safety devices | Safety devices use infrared sensing, safe and reliable | |||||
| Cutting speed | 200-2000mm/s | |||||
| Cutting thickness | ≤50mm Other thicknesses can be customized according to the material | |||||
| Applicable materials | gasket,cotton, linen, silk, blends, fibers, leather, etc. | |||||
| Material fixing method | Vacuum partition adsorption | |||||
| Transmission port | Network port | |||||
| Transmission system | Yaskawa servo motor, linear linear guide, timing belt, lead screw | |||||
| rated power | 11kw | |||||
| Rated voltage | 380V±10%/220V±10% Optional | |||||
| Control System | Chinese and English LCD touch screen | |||||
| Operating environment | Operating environment Temperature 0-40°C Humidity 20%-80%RH | |||||
| Software | Automatic nesting software, template entry software（Optional） | |||||
| Support file format | AI、PLT、DXF、CDRetc | |||||
| Overall size | 3570x2290x1165mm | 3570x2500x1165mm | 3570x25800x1165mm | |||
