What is PVC coated cloth?
PVC plastic coated cloth is a kind of composite material that has both properties of PVC material and cloth blank by coating a layer of PVC material on the surface of canvas, linen and other fabrics. The surface of this composite material is smoother and inherits the excellent physical and chemical properties of pvc material: non-flammable, high strength, good weather resistance, excellent geometric stability, oxidation resistance, reduction resistance, good low temperature flexibility, It has good tensile and impact resistance, and this material has a lower density and lighter weight than pure pvc material.
Because of its excellent performance, pvc plastic coated cloth is widely used in automobile canopy, train cover, ship, freight yard cover and other fields, as well as glass factory, lumber factory, fertilizer factory, machinery, hardware industry, container factory, logistics Industry, railway transportation industry, warehousing industry.
With the change of the thickness of the pvc material and the content of various stabilizers, the pvc plastic-coated cloth can have various characteristics according to our needs, to meet the application of a variety of different industries, and the wide range of application industries makes the pvc plastic-coated cloth market getting bigger.
Later, a laser cutting machine that replaced manual cutting appeared, but it is the biggest fatal point of the laser cutting machine in terms of environmental protection, and the finished product will be yellowed and scorched due to the laser, which requires secondary processing. With the development of science and technology, the vibrating knife cutting machine has appeared. The vibrating knife cutting machine uses the blade to cut. The green and pollution-free characteristics have attracted the attention of many businesses. Moreover, the edges of the cut material are neat and free of burrs, and no secondary processing is required. It is now the equipment of choice in flexible material cutting.
Detailed parameters of PVC coated cloth cutting machine
| Technical parameters / model | AOL1625 | AOL1825 | AOL2125 | Accept special model customization | ||
|---|---|---|---|---|---|---|
| Effective working area | 1600x2500mm | 1800x2500mm | 2100X2500 | |||
| Multi-head optional | Double head optional efficiency doubled, double gantry optional, double head mutual shift optional, length can be customized | |||||
| Multi-function tool | Vibrating knife full cutting, high power active round knife, punching tool, pneumatic knife, multi-layer knife | |||||
| safety devices | Safety devices use infrared sensing, safe and reliable | |||||
| Cutting speed | 200-2000mm/s | |||||
| Cutting thickness | ≤50mm Other thicknesses can be customized according to the material | |||||
| Applicable materials | foam, vinyl, cardboard, paper, lable, fabric, gasket,cotton, linen, silk, blends, fibers, leather, etc. | |||||
| Material fixing method | Vacuum partition adsorption | |||||
| Transmission port | Network port | |||||
| Transmission system | Yaskawa servo motor, linear linear guide, timing belt, lead screw | |||||
| rated power | 11kw | |||||
| Rated voltage | 380V±10%/220V±10% Optional | |||||
| Control System | Chinese and English LCD touch screen | |||||
| Operating environment | Operating environment Temperature 0-40°C Humidity 20%-80%RH | |||||
| Software | Automatic nesting software, template entry software（Optional） | |||||
| Support file format | AI、PLT、DXF、CDRetc | |||||
| Overall size | 3570x2290x1165mm | 3570x2500x1165mm | 3570x25800x1165mm | |||
AOL SERVICE
After sale service
1).Three years free warranty(except consumable parts), main parts are free of charge.when problems happened because of quality problem during this period.
2).Life time free maintenance service.
3).Consumable parts(like blade, table cover) alway supply at cost price when needed.
4).A free operation training in our factory, and if don’t have enough time, we will send a detailed training video.
5).24 hours online service, free technical support with different languages.
6).Door to door technical support when needed.
If you could kindly provide us a few information, that would be very helpful for us.
Eight reasons to AOL CNC cutting machine
1. Advanced brand: ten years of professional CNC blades
2. R & D advantages: a number of patented technologies, so that the company has a deep deposit
3. Quality assurance: all products have passed European CE certification. US FDA certification
4. High-quality materials: All CNC cutting machine accessories are selected from industry-leading brands.
5. Advanced technology: starting from Germany, foreign advanced technology, technical support
6. High efficiency: implement one-to-one service to improve the efficiency of corporate feedback
7. Personalized customization: With the development and design functions, customers can do whatever they want
8. After-sales service: provide three-year warranty service and 24-hour online solutions.
About AOL
AOL CNC Equipment Co., Ltd. is a high-tech enterprise specializing in the development, manufacturing, sales and after-sales service of flexible material cutting. Various types of cutting machines such as labeling machines can meet the cutting processing of metal materials and flexible materials of different materials, and are widely used in advertising packaging, composite materials, carpet industries, clothing textiles, automotive interiors, and leather industries.
The company is strong. AOL CNC Equipment Co., Ltd. is a high-tech industry in China and an AAA-level credit enterprise. The product quality has undergone multiple tests and the after-sales system is complete. It has provided reliable CNC cutting machines to more than 8,000 users worldwide. Provide professional industry cutting assembly line solutions for many users.
Media information
AOL CNC cutting machine is suitable for product customization or sample cutting. It can automatically and accurately perform cutting and other processing. CNC cutting machine supports different types of cutting, (such as through cutting, kiss cutting. V-groove, compliance, milling, etc.
Want to know more machine performance and other information, please leave a message for professional reply.
AOL intelligent blade cutting machine has high precision and high efficiency. Our professional after-sales service can provide automatic cutting solutions for various industries.
