Functional features of Paper Board Cutting Machine
– Auto sheet loading and receiving;
– CCD camera registration system for precise cutting;
– Drag cut, kiss-cut, creasing and drawing in one pass;
– Intelligentize control and easy to operate;
– Exact cutting size and high cutting speed;
– This Flatbed vinyl cutting plotter can read QR code to cut.
– Continuous cutting of coils material
-HD camera automatically recognizes the mark points (2-4 mark points), and automatically cuts the recognition
-The lifting platform realizes vacuum adsorption and feeding of the plates.
Advantage of Flatbed vinyl cutting plotter
1. High frequency electric oscillating/vibration knife: There would be much more cutting material and cutting thickness to meet different demands of customers.
2. Integration of intelligent cutting/ indentation/drawing –meet your whole trip of creative processing: cutting labels at all shapes, cutting and indentation of carton in all shapes.
3. Precise auto-positioning system: Equipped with HD CCD camera, it could achieve the precise auto-positioning of all materials and the automatic registering, which solves the imprecise manual positioning and the deforming printing, so as to reach the simple and precise cutting.
4. Barcode management system: Scan the barcode to read the cutting task rapidly.
5. Automatic feeding system: Automatic feeding system to make the cutting more efficient.
Application material of Paper Board Cutting Machine
Flatbed vinyl cutting plotter is widely used in the advertising packaging industry to help the realization of design ideas, including, paper, board, sticker, vinyl, corrugated cardboard, cardboard, gray cardboard, KT board, POP paper and so on.
For a wide range of material cutting applications, Flatbed vinyl cutting plotter is powerful enough to bring more and more value.
It can realize not only through cutting, but also kiss cutting, half cutting, bevel cutting, indentation, drag knife cutting and other functions, so as to realize the economic development of the enterprise.
Cutting display of Paper Board Cutting Machine
Parameter of Paper Board Die Cutter
|Effective working area10||1000*700mm|
|Multi-function cutting head||The combination of Multi-function cutting head and holders, be with full cut, kisscut, creasing wheel,v-cut and laser red light positioning functions, CCD positioning, Camera extract large contour to cut|
|Tools||Oscillating knife, Milling tool, pneumatic knife, V-cut, crease wheel, kiss cut, drag knife|
|Overall size||2520*1080*1280mm L’W’H|
|Control panel||LCD touch screen|
|Drive system||Imported servo motor, linear guid, synchronous belt, screw|
|Cutting material||Paperboard, grey board, KT board, pvc foam board, honeycomb board, car sticker, lamp piece, PP Adhesive material, printing cloth, banner cloth, all kinds of corrugated board, EPE foam, EVA, PVC board, acrylic board, thick foam and so on|
|Instruction system||HP- GL Compatible format|
|Rated power||2. 2KW|
|Cutting thickness||(According to different material)|
|Material fixed way||Vacuum adsorption|
|Auto feeding system||Acuum sucker adsorpting sheet|
Details of Packaging
1. Outer packaging: standard seaborne export plywood box.
2. Inner packaging: stretchable film and plastic film to prevent moisture. Flexible packaging machine accessories
3. Personalization: If you have special requirements for packaging, you can negotiate friendly.
There are many options for transportation, and the default is sea transportation. If you have special requirements, please specify in advance.
Price, according to your destination information, transaction method, transportation method, we will provide you with a specific quotation.
After sale service
1. Our standard warranty period starts from the completion of delivery. We provide you with a three-year warranty service and professional machine maintenance.
2. The wearing parts (blade, countertop) are sold to users at the lowest price.
we have our own factory. After placing the order, we will start manufacturing the sticker cutting machine. At the same time, we will make a reasonable delay based on the order volume of the month. Our delivery time is about 15-20 days on average, if you want to specify a time, we can arrange a reasonable time to complete the delivery.
Eight reasons to AOL CNC cutting machine
1. Advanced brand: ten years of professional CNC blades2. R & D advantages: a number of patented technologies, so that the company has a deep deposit
3. Quality assurance: all products have passed European CE certification. US FDA certification
4. High-quality materials: All CNC cutting machine accessories are selected from industry-leading brands.
5. Advanced technology: starting from Germany, foreign advanced technology, technical support
6. High efficiency: implement one-to-one service to improve the efficiency of corporate feedback
7. Personalized customization: With development and design functions, customers can do whatever they want
8. After-sales service: provide three-year warranty service and 24-hour online solutions.
AOL CNC Equipment Co., Ltd. is a high-tech enterprise specializing in the development, manufacturing, sales and after-sales service of flexible material cutting and laser cutting machines, mainly including CNC intelligent blade cutting machines, laser cutting machines, laser fiber cutting machines, and laser cutting machines. Various types of cutting machines such as labeling machines can meet the cutting processing of metal materials and flexible materials of different materials, and are widely used in advertising packaging, composite materials, carpet industries, clothing textiles, automotive interiors, and leather industries. In addition, AOL also has an independent CNC cutting machine brand AOYOO.
The company is strong. AOL CNC Equipment Co., Ltd. is a high-tech industry in China and an AAA-level credit enterprise. The product quality has undergone multiple tests and the after-sales system is complete. It has provided reliable CNC cutting machines for more than 8,000 users worldwide. Provide professional industry cutting assembly line solutions for many users,
AOL is committed to multi-industry flexible material cutting solutions for global users. The annual output of high-quality CNC cutting machines in the AOL factory can reach 2000 units, and each machine is provided with a three-year warranty service.
AOL CNC cutting machine is suitable for product customization or sample cutting. It can automatically and accurately perform cutting and other processing. CNC cutting machine supports different types of cutting, (such as through cutting, kiss cutting. V-groove, compliance, milling, etc.
AOL intelligent blade cutting machine has high precision and high efficiency. Our professional after-sales service can provide automatic cutting solutions for various industries.
