Feature of Cardboard Autofeeding Flatbed Cutter
1. Instead of traditional crafts, improve cutting efficiency.
2. Small paper cutting machine system controls the cutting process to ensure uniform cutting quality.
3. Set cutting parameters to start cutting, no need to make templates.
4. The quality of small batch customization and sample cutting is more guaranteed.
Advantages of Feature of Cardboard Autofeeding Flatbed Cutter
High frequency electric oscillating/vibration knife: There would be much more cutting material and cutting thickness to meet different demands of customers.
Integration of intelligent cutting/ indentation/drawing –meet your whole trip of creative processing: cutting labels at all shapes, cutting and indentation of carton in all shapes.
Precise auto-positioning system: Equipped with HD CCD camera, it could achieve the precise auto-positioning of all materials and the automatic registering, which solves the imprecise manual positioning and the deforming printing, so as to reach the simple and precise cutting.
Barcode management system: Scan the barcode to read the cutting task rapidly.
Automatic feeding system: Automatic feeding system to make the cutting more efficient.
Specifications of Advertising Board Vinyl Sticker Cutter
AOL-1070 series cutting plotter is suitable for the sample pattern’s design and manufacturing in the light, artwork, and color box industries.
|Effective working area10||1000*700mm|
|Multi-function cutting head||The combination of Multi-function cutting head and holders, be with full cut, kisscut, creasing wheel,v-cut and laser red light positioning functions, CCD positioning, Camera extract large contour to cut|
|Tools||Oscillating knife, Milling tool, pneumatic knife, V-cut, crease wheel, kiss cut, drag knife|
|Overall size||2520*1080*1280mm L’W’H|
|Control panel||LCD touch screen|
|Drive system||Imported servo motor, linear guid, synchronous belt, screw|
|Cutting material||Paperboard, grey board, KT board, pvc foam board, honeycomb board, car sticker, lamp piece, PP Adhesive material, printing cloth, banner cloth, all kinds of corrugated board, EPE foam, EVA, PVC board, acrylic board, thick foam and so on|
|Instruction system||HP- GL Compatible format|
|Rated power||2. 2KW|
|Cutting thickness||≤80mm(According to different material)|
|Material fixed way||Vacuum adsorption|
|Auto feeding system||Acuum sucker adsorpting sheet|
Detail of Advertising Board Vinyl Sticker Cutter
About Cardboard Autofeeding Flatbed Cutter
Packaging ofCardboard Autofeeding Flatbed Cutter
1. Full film packaging machine (to prevent moisture)
2. Anti-collision edging
3. Wooden box packaging (standard specifications)
4. A warning sign is posted on the packaging box
Shipping of Cardboard Autofeeding Flatbed Cutter
in general,the FOB delivery method is adopted, and the price is determined according to your designated delivery port and transportation distance. Please leave a message for reference, we have professional staff to calculate the price for you.
After sale service
1. Our standard warranty period starts from the completion of delivery. We provide you with a three-year warranty service and professional machine maintenance.
2. The wearing parts (blade, countertop) are sold to users at the lowest price.
we have our own factory. After placing the order, we will start manufacturing the sticker cutting machine. At the same time, we will make a reasonable delay based on the order volume of the month. Our delivery time is about 15-20 days on average, if you want to specify a time, we can arrange a reasonable time to complete the delivery.
Eight reasons to choose Sticker cutting machine plotter
1. Advanced brand: ten years of professional CNC blades2. R & D advantages: a number of patented technologies, so that the company has a deep deposit
3. Quality assurance: all products have passed European CE certification. US FDA certification
4. High-quality materials: All CNC cutting machine accessories are selected from industry-leading brands.
5. Advanced technology: starting from Germany, foreign advanced technology, technical support
6. High efficiency: implement one-to-one service to improve the efficiency of corporate feedback
7. Personalized customization: With development and design functions, customers can do whatever they want
8. After-sales service: provide three-year warranty service and 24-hour online solutions.
AOL CNC Equipment Co., Ltd. is a high-tech enterprise specializing in the development, manufacturing, sales and after-sales service of flexible material cutting and laser cutting machines, mainly including CNC intelligent blade cutting machines, laser cutting machines, laser fiber cutting machines, and laser cutting machines. Various types of cutting machines such as labeling machines can meet the cutting processing of metal materials and flexible materials of different materials, and are widely used in advertising packaging, composite materials, carpet industries, clothing textiles, automotive interiors, and leather industries. In addition, AOL also has an independent CNC cutting machine brand AOYOO.
The company is strong. AOL CNC Equipment Co., Ltd. is a high-tech industry in China and an AAA-level credit enterprise. The product quality has undergone multiple tests and the after-sales system is complete. It has provided reliable CNC cutting machines for more than 8,000 users worldwide. Provide professional industry cutting assembly line solutions for many users.
For more machine information, please leave a message in the left or bottom box, waiting for professional reply.
