Specifications of AOL Automatic Car Seat Cover Mat Cutting Machine:
| Technical parameters / model | AOL-1625-GA6 | AOL-1825-ZS8 | AOL-2125-ZS10 | Accept special model customization | ||
| Effective working area | 1600x2500mm | 1800x2500mm | 2100X2500 | |||
| Multi-head optional | Double head optional efficiency doubled, double gantry optional, double head mutual shift optional, length can be customized | |||||
| Multi-function tool | Vibrating knife full cutting, high power active round knife, punching tool, pneumatic knife, multi-layer knife | |||||
| safety devices | Safety devices use infrared sensing, safe and reliable | |||||
| Cutting speed | 200-2000mm/s | |||||
| Cutting thickness | ≤50mm Other thicknesses can be customized according to the material | |||||
| Applicable materials | gasket,cotton, linen, silk, blends, fibers, leather, etc. | |||||
| Material fixing method | Vacuum partition adsorption | |||||
| Transmission port | Network port | |||||
| Transmission system | Yaskawa servo motor, linear linear guide, timing belt, lead screw | |||||
| rated power | 11kw | |||||
| Rated voltage | 380V±10%/220V±10% Optional | |||||
| Control System | Chinese and English LCD touch screen | |||||
| Operating environment | Operating environment Temperature 0-40°C Humidity 20%-80%RH | |||||
| Software | Automatic nesting software, template entry software（Optional） | |||||
| Support file format | AI、PLT、DXF、CDRetc | |||||
| Overall size | 3570x2290x1165mm | 3570x2500x1165mm | 3570x25800x1165mm | |||
ADVANTAGES
Advantage of Automatic Car Seat Cover Mat Cutting Machine
The automotive industry moves quickly, and every detail is important, the interiors functionality, the technological perfection of mechanical components, all is studied to achieve high performance and cheapness.
AOL Automatic Car Seat Cover Mat Cutting Machine can offer cutting solutions for leather or textile interiors, for mechanical parts made of composites or foams. car floor mat cutting equipment
innovative software and hardware solutions give you complete control over your OEM or Tiered Supplier operation – with the flexibility to adapt to changes quickly.
Software advantage of AOL Automatic Car Seat Cover Mat Cutting Machine
- Car seat cover knife cutting machinehas AOL-CUT self-developed software one-click import, general worker takes 2 hours to be skilled.
2.Super typesetting master software, material utilization rate increases more than 10%.
3.Unique multi-partition technology, adsorption capacity increased by more than 5 times
4.Car floor mat cutting equipment has projection positioning system: In actual cutting process, it is difficult for users to accurately align the material with the cutting pattern. This system can project the cutting pattern on the processing table with 1: 1, which is convenient for users to feed the alignment.
The user of Aol car seat cover mat cutting machine, can also place the irregular material into the projection area for the alignment cutting, which greatly improves the utilization of the material.
Hardware advantage of AOL Automatic Car Seat Cover Mat Cutting Machine
1.Taiwan linear guide rail transmission system, precision ±0.1 mm.
2.Japanese Panasonic servo system, production efficiency increases more than 3 times.
3.AOL’s unique tools exchange system, cutting, punching, marking automatically finish
- Automatic pulling and receiving, save time and energy.
- Aol car seat cover mat cutting machine has won 5 patents technology certifications at home and abroad
SAMPLE
AOL’s main products include intelligent blade cutting machine, 3D crystal inner engraving machine, laser marking machine and laser fiber cutting machine. Welcome to consult!
About AOL
Jinan AOL CNC Equipment Co., Ltd was established in 2014 and is located in Jinan,enjoying convenient transportation and beautiful environment. Our company covers an area of 9500m square meters and has 139 employees. We are specialized in cutting machine. Our company has rich experience in the cutting machine industry. Our main products include CNC knife cutting machine, CO2 laser cutting machine, CO2 Laser engraving machine.
Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction.
In addition, we have obtained CE SGS SO BV and more certificates. Besides, we are making great efforts to develop new products to meet different requirements.
Our machine Sells well in all exported to clients in such kinds of countries and regions as America, Europe, Africa, Asia,Australia and more.
Company strength of AOL
- Foreign trade practitioners with 12 years of experience specialize in docking related orders with customers
- Electricians and fitters with 30 years of experience instruct and participate in the installation of the machine
- AOL invests millions of research and development funds every year to improve machine performance and develop new products
- Hot sales in more than 40 countries around the world, and praised by customers, the repurchase rate is as high as 40%
- Currently, China’s only manufacturer of cutting machines that promises a three-year warranty
